Sewn Filter Media Bags , Gas Filtration High Efficiency Filter Bags 0.2 - 10um
Liquid filter bag Detailed Product Description Type: Liquid Filter Bag Material: PEFE Size: 1#,2# Micron: 0.2-10 Um Ring Material: Metal Ring Bag Body Structure: Sewn Package: Standard Export Package Usage: Water Filtration/Gas Filtration Liquid Filter Ba| Type: | Liquid Filter Bag | Material: | PEFE |
|---|---|---|---|
| Size: | 1#,2# | Micron: | 0.2-10 Um |
| Ring Material: | Metal Ring | Bag Body Structure: | Sewn |
| Package: | Standard Export Package | Usage: | Water Filtration/Gas Filtration |
Liquid Filter Bags 0.2 - 10um Micron Sewn Bag Body Structure Gas Filtration
Liquid filter bag Description:
Low shrinkage rate even if under high temperature 260℃
Acid and alkali Resistance, corrosion resistance,aging resistance
Can be used under high humidity environment
High temperature grade
Anti acid ,anti alkali, chemical resistance
High porosity ,good air permeability
Good price quality
High filtration efficiency ,long service life
Good anti abrasion
Laminated compound,grads counterchange
Liquid filter bag Specification:
Liquid filter bag Sheet1:
| Type | Size | Bag Body Structure | Bag top Structure | Micron Rating(um) |
| High Temperature Filter Bags | 01#,02# | Sewn | Metal Ring | 0.2-10 |
| PTFE-ptfe felt |
Liquid filter bag Sheet2:
| Compositions | 100% PTFE | |
| Weight (g/m2) | 800 | |
| Thickness (mm) | 1.0～1.5 | |
| Air permeability(L/m2/S) | 1.8-3.6 | |
| Tensile strength(N/5×20cm) | Warp | ≥600 |
| Weft | ≥800 | |
| Tensile Elongation(％) | Warp | <12 |
| Weft | <15 | |
| Continous operating temperature (℃) | ≤250 | |
| Short time operating temperature(℃) | 280 | |
| Anti-acid | Excellent | |
| Anti-alkali | Excellent | |
| Anti-abrasion | Excellent | |
| The stability of water solution | Excellent | |
| Finishing treatment | Heat Set | |
Liquid filter bag Sheet 3:
| Filter bag size | Max Flow(m3/h) | Filter Area(m2) | Volume(L) | Diameter(inch) | Length(inch) |
| Size 01# | 20 | 0.25 | 8 | 7 | 17/16 |
| Size 02# | 40 | 0.5 | 17 | 7 | 32/33 |
Liquid filter bag Features:
PTFE needle felt are produced from 100% PTFE fiber which has been punched in three-dimentional structure. They have excellent features such as excellent flexibility, molding capability, high tensile strength, creep resistance, high and low temperature resistance, corrosion resistance and anti-aging. 100% PTFE filter material can meet requirements in hostile environments of temperature fluctuating and acid & alkali in all PH range. The lifespan of PTFE filter material will be guaranteed for over 4 years as long as the temperature is controlled under the maximum operating temperature.
Liquid filter bag Application:
1. Paints & lacquer industry
2. Wastewater treatment
3. Pharmaceutical industry
4. Food industry
5. Chemical industry
6. Beer, wine & spirit industry
7. Adhesive.
